Technical Specifications
| No. of Collectors |
02 No. |
| Type |
Copper, selectively coated with “NALSUN” Black Chrome coating. |
| Size |
2030mm L x 1030mm W x 100mm H |
| Absorber Material |
Copper – Copper absorber. |
| No. of Fins |
9 No’s per collector |
| Header Tubes |
Copper, Ø25 mm, 22 SWG. |
| Riser Tubes |
Copper, Ø12.5 mm, 24 SWG. |
| Header Protective coating |
Polyurethane based coating. |
| Riser to Fin Joining |
Ultra Sonic Metal welding |
| Collector Box |
Aluminum. |
| Protective coating on Collector Box |
Pure Polyester powder coated – Golden Yellow. |
| Glass retaining angle / Aluminum |
25mm Pure Polyester Powder coated – Black. |
| Collector back sheet |
Aluminum Screwed to the frame. |
| Back, Corner Sealing |
Non Acidic Silicon sealant through corners and screw joint. |
| Top Cover/Glazing |
Toughened glass, 4mm thick. |
| Glass Beading |
High quality EPDM Rubber – Single Piece. |
| Absorber Flanges |
4 mm Thick Machined brass flanges, 63 mm dia, 4 bolt holes. |
| Gaskets and Grommets |
High quality EPDM special shaped full Gaskets and Grommets. |
| Insulation Bottom |
Rock wool, 50 mm 48 kg/m3 density. |
| Insulation Side |
Rock wool, 25 mm 48 Kg/m3 density. |
| Reflective foil |
Aluminum 50 microns thick for bottom and 0.45 mm for sides. |
| Collector Supports |
Fabricated and Duly powder coated Mild Steel Sections. |
| Inner Tank Material. |
GI Inner Tank |
| Type |
Cylindrical – horizontally assembled. With Anoad Road |
| Size and Thickness |
Ø460mm, Length 2050mm. |
| Insulation |
P U F.40-50mm. |
| Outer Cladding |
Pre coated galvanized steel/Aluminum. |
| Outer Finishing |
Pure Polyester Powder Coating. |
| Outer Finish Color |
White&Blue combination. |
| Back up Heater |
2 KW With thermostat control 230 V AC. |
| Tank Supports |
Fabricated and powder coated M.S. Tube. |
| Tank Testing |
Factory pressure tested for pressurized systems is at 8 Kg/cm². |
| Normal Working pressure of the system |
Less than 4 Kg/cm². |
| Interconnection Tank and Collector |
EPDM Pipe. |
| Warranty |
5 Years |
Collector box is made of specially extruded aluminium channel for durability and good aesthetic look.
The top cover is made of toughened glass with high transmissivity.
Absorber fins are made of high-quality aluminium and coated with high absorptivity low emissivity solar selective coating
The risers and headers are made of thick gauged high quality copper tubes.
The absorber fins are ultrasonically bonded to the riser tubes for high thermal efficiency and longer life.
The storage tank is made of glass lined mild steel and is well insulated with PUF to minimise heat loss to the surroundings.
Clear sunny days, the system is capable of generating 50°C to 70°C of hot water.
Weather proof, ISI marked back up heater with adjustable, automatic temperature
Description
200 LPD FPC Anu Solar Water Heater Suppliers in Hyderabad
High-Quality 200 LPD FPC Anu Solar Water Heater Suppliers in Hyderabad – Mithra Products
At Mithra Products, we are proud to be trusted 200 LPD FPC Anu Solar Water Heater suppliers in Hyderabad, offering top-grade solar water heating solutions that combine performance, durability, and energy efficiency. Designed with advanced Flat Plate Collector (FPC) technology, the 200 LPD FPC Anu Solar Water Heater is perfect for small to medium-sized families, ensuring reliable hot water supply while reducing electricity bills.
We are leading 200 LPD FPC Anu Solar Water Heater dealers in Hyderabad, catering to residential and commercial clients who seek sustainable and cost-effective hot water systems. Our pressurized models are built to work efficiently in multi-story buildings and homes with overhead tanks, offering consistent water pressure and heating capacity throughout the day.
The Solar Water Heater from Anu is built with corrosion-resistant materials, highly efficient collectors, and insulated tanks that retain heat longer, making it an ideal choice for year-round usage. As experienced suppliers, Mithra Products ensures seamless installation, genuine products, and expert customer support to make your switch to solar as smooth as possible.
Whether you’re upgrading your current system or installing a new one, trust Mithra Products, the most reliable 200 LPD FPC Anu Solar Water Heater suppliers in Hyderabad, for quality products and prompt service. Invest in the future of clean, efficient, and cost-saving energy with our premium Solar Water Heater solutions. Contact us today to learn more!
Top Features of 200 LPD FPC Anu Solar Water Heater
- Heavy duty magnesium anode rods extend life of the tank.
- Easy tank cleaning facilitated by the side-
- opening design.
- Suitable for high-rise buildings.
- FPC GL series SWH offers a 5-year warranty*.
- Maximum heat retention with high-density
- PUF insulation.
- Sturdy construction with powder-coated MS angle stand.
Terms And Conditions
01. Delivery & Installation Available all over Telangana State & Bengaluru Rural & Urban.
02. Prices are including Taxes.
03. Transportation & Installation is Free Within Hyderbad ORR & Bengaluru Urban , Bengaluru Rural. For other locations – Extra charges for Transportation & Installation.
04. Plumbing Work/Electrical Work/if any civil work is under customer Scope.
05. Backup heater is Optional, and extra cost. Click here to purchase Backup heater.
06. Warranty – is according to manufacutrers terms & conditions.
07. Space Required at Terrace / Installation Place: East to West direction – 8 Feet & south – north direction – 8.5 feet .
